VOE14645595 Hose for Volvo Excavator Parts

Select the number of specifications

Please check the product information you want!

Product Detail

Volvo EC480D(S/N 210001-/260001- 270001-/280001-) VOE14645595 Xtraflex/5000 wholesale

Part Name: VOE14645595 Hose
KDSORT: 410
UE: U
ANT1: 1
ANT2: 1
Hose Recipe Asmoverall Length MM: 1570
Hose Recipe Asmoverall Length Inch: 61.81
Hose Recipe Asmoverall Length ToL MM: +/- 1%
Hose Recipe Asmoverall Length ToL inch: +/- 1%
Hose Recipe Fitting OrIentationtol Tol Degrees: +/- 5 degrees
Hose Recipe Hydraulic Hose Standard: EN (474-1) (5.18.13 Hydraulic Hosees)
Hose Recipe Safety Standard: EN 982-1996
Hose Recipe Assembly Instruction Reference: 1076838
Hose Recipe Version: 5
Hose Recipe Status: A
Hose Recipe Protector Length MM: 1400
Hose Recipe Protector Length INCH: 55.12
Hose Recipe Vendor: MANULI
Hose Recipe Grade: 1
Hose Part Hose Description: Xtraflex/5000
Hose Part Hose Size DN: 31
Hose Part Hose Size Inch: 1.1/4"
Hose Part Hose Dash: -20
Hose Part Hose Pressure Class MPA: 35.0
Hose Part Hose Pressure Class PSI: 5075
Hose Part Hose Pressure Class BAR: 350
Hose Part Hose Standard ISO: ISO 18752-C
Hose Part Hose Standard SAE: Volvo 106
Hose Part Hose Standard EN: Volvo 106
Hose Part Hose Standard MSHA: MSHA 2G-IC-126C/8-1
Hose Part Hose Structure: Wire spiralled four layer
Hose Part Hose Remark: Extreme flexibility
Hose Part Hose Outer Diameter MM: 46
Hose Part Hose Outer Diameter INCH: 1.81
Hose Part Cancelled: N
Hose Part Vendor: MANULI
Hose Part Grade: 1
Hose Part In Program: Y
Catalog: 20591/916/120
Looking for Part NO.VOE14645595?
We offer Kobelco / Komatsu / Deutz / SUMITOMO / CASE / HYUNDAI aftermarket parts. You can get this part with wholesale price start from 1 pcs. Contact us get the best price.
VOE14645595 for Volvo Working hydraulic, dipper arm cylinder on boom.(1029981 assembly)
Volvo VOE14645595 Hose suitable for 1029981 Working hydraulic, dipper arm cylinder on boom. assembly.
Volvo VOE14645595(c.1029981) Xtraflex/5000
Ref: 1029981 / 16 / 2
VOE8300357 / U / WITHOUT, 7,0M Hose rupture v. for dip arm, leak-off line on boom
VOE8292953 / U / 6.5M ME BOOM+2.55M ARM Siberian option package
VOE8292952 / U / 7,0M BOOM+3,35M ARM Siberian option package
20591/916/130, 20591/916/120
We supply SAMSUNG / HYUNDAI / SUMITOMO / Doosan / ISUZU / MITSUBISHI spare parts. MOQ 1 pcs is available! VOLVO Part NO.VOE14645595 is on sale now!
Part NO. VOE14645595 for Volvo EC480D(S/N 210001-/260001- 270001-/280001-)
EXCAVATOR VOLVO EC480D
BASIC MACHINE
Product number 8288862, Serial number 210001-210514, 260001-260044, 270001-, 280001-
SUB BASIC MACHINE
Product number 8291485, Serial number 210048-
Product number 8291486, Serial number 260001-260044, 270001-, 280001-
Product number 8291526, Demolition, Serial number 210052-
Product number 8301353, Serial number 274947-, 281024-
Product number 8301354, Serial number 274947-, 281024-
CAB
PART NO. 11294085, 11294086
ENGINE
PART NO. 15117871, 13L , EU, 8288863
part not stocked as spare part
PART NO. 15049436, 13L, US, 8290446
part not stocked as spare part
PART NO. 15173113, replacement version
PART NO. 15049434, 13L, 8290246
part not stocked as spare part
PART NO. 17216264, replacement version
PART NO. 15049435, 13L, 8290247
part not stocked as spare part
PART NO. 17216264, replacement version
We have our own production/R&D factory, high quality and low price are our advantages.
With more than 10 years of machinery industry experience, we have received praise from all over the world (customer / reseller / manufacturers / distributors).
Original VOE14645595 included regular invoice.
Used/Second hand VOE14645595 provide 3-12 months quality guarantee .
All Taxes included, no more hidden fee.
Choose us, get permanent online support, our Golden Engineers are ready.
